32 AIRFLOW CHARTS (RNC6-HEX-TPD/5-HEX-TPF)
The RNC6-HEXw-TPD and RNC5-HEX-TPF units have three airflow charts for their installer adjustable high
speed settings. Refer to Installer Selectable High Speed Settings in this manual for instructions on how to
adjust the circuit board DIP switches.
Hi 3
Hi 2
Hi 1
Pressure
Drop
Supply
Airflow
Exhaust
Airflow
Pressure
Drop
Supply
Airflow
Exhaust
Airflow
Pressure
Drop
Supply
Airflow
Exhaust
Airflow
(“w.g.)
(Pa)
(cfm)
(cfm)
(“w.g.)
(Pa)
(cfm)
(cfm)
(“w.g.)
(Pa)
(cfm)
(cfm)
0.530
132
84
85
0.530
132
71
69
0.530
132
58
55
0.540
134
83
84
0.540
134
70
68
0.540
134
57
54
0.550
137
82
83
0.550
137
68
67
0.550
137
55
53
0.560
139
80
81
0.560
139
67
65
0.560
139
54
52
0.570
142
79
80
0.570
142
65
64
0.570
142
52
51
0.580
144
78
79
0.580
144
64
63
0.580
144
50
49
0.590
147
76
78
0.590
147
62
62
0.590
147
49
48
0.600
149
75
77
0.600
149
61
60
0.600
149
47
47
0.610
152
73
75
0.610
152
59
59
0.610
152
46
46
0.620
154
72
74
0.620
154
58
58
0.620
154
44
44
0.630
157
71
73
0.630
157
56
56
0.630
157
42
43
0.640
159
69
72
0.640
159
54
55
0.640
159
41
42
0.650
162
68
70
0.650
162
53
54
-
-
-
-
0.660
164
66
69
0.660
164
51
52
-
-
-
-
0.670
167
65
68
0.670
167
49
51
-
-
-
-
0.680
169
63
66
0.680
169
48
49
-
-
-
-
0.690
172
62
65
0.690
172
46
48
-
-
-
-
0.700
174
60
63
0.700
174
44
47
-
-
-
-
0.710
177
58
62
0.710
177
42
45
-
-
-
-
0.720
179
57
61
0.720
179
41
44
-
-
-
-
0.730
182
55
59
0.730
182
-
42
-
-
-
-
0.740
184
53
58
0.740
184
-
41
-
-
-
-
0.750
187
52
56
0.750
187
-
40
-
-
-
-
0.760
189
50
54
-
-
-
-
-
-
-
-
0.770
192
48
53
-
-
-
-
-
-
-
-
0.780
194
46
51
-
-
-
-
-
-
-
-
0.790
197
45
50
-
-
-
-
-
-
-
-
0.800
199
43
48
-
-
-
-
-
-
-
-
0.810
202
41
46
-
-
-
-
-
-
-
-
0.820
204
-
45
-
-
-
-
-
-
-
-
0.830
207
-
43
-
-
-
-
-
-
-
-
0.840
209
-
41
-
-
-
-
-
-
-
-
0.850
212
-
40
-
-
-
-
-
-
-
-
