LifeSpan SP-310 User Manual

6
SP-310
3. PARTS LIST
NO NAME QUANTITY SPEC
1L PEDAL 1
JD-301（9/16"）L
1R PEDAL 1
JD-301（9/16"）R
2 END CAP1 5 60*30*1.5
3 CARRIAGE BOLT 4 GB/T 12-1988 M8*42
4 REAR STABILIZER 1 WELDING
5 FLAT WASHER 4
GB/T 95-2002 8
6 DOMED NUT 4
GB/T 802-1988 M8
(H=16mm)
7 SPRING ADJUSTMENT KNOB 3 φ57*62 (M16*1.5)
8 PLASTIC SLEEVE 3 53.5*23.5*1.5
9 LOCK NUT 2 M33*1*4
10 VERTICAL SEAT POST 1 WELDING
11 END CAP2 1 53.5*23.5*1.5
12 SEAT POST 1 WELDING
13 SEAT 1 DD-2681
14 STOPPER 4 φ32*37/(M8X25)
15 FRONT STABILIZER 1 WELDING
16 MAIN FRAME 1 WELDING
17 HANDLEBAR POST 1 WELDING
18 HANDLE BAR 1 WELDING
19 SPRING WASHER 4 GB/T 859-1987 8
20 BOLT 8 GB/T 70.2-2000 M8*15
21 HANDLEBAR COVER 1 115*89*75 (60g)
22 COMPUTER HOLDER 1 δ2.5
23 COMPUTER 1 HS-6065
24 BRAKE KNOB 1 112*32*7
25 ADJUSTMENT KNOB 1 φ38*79
26 LITTLE PLASTIC RING 1 14*8*9
27 PLASTIC RING 2 φ20*φ9*3
28 FIXING NUT 1 2
GB/T 6177.2-2000 M10*1.25
29 CRANK END CAP 2 φ23*7.5
30 SHEET IRON 1 δ5
31 LOCK NUT 7 GB/T 889.1-2000 M8
32 CHAIN WHEEL 1
A7K-16 1/2"*1/8" 16T（1.37"）
33 LEFT CRANK 1 170*27
34 CRANK COVER 1 φ56*28
35 BEARING 2 6004ZZ
36 RIGHT CRANK 1 170*27
