Lifetime 51544 - Hardware Identifier; Pole Assembly Hardware; Pole to Base Assembly Hardware; Backboard to Rim Assembly Hardware

11
HARDWARE IDENTIFIER
0/,%!33%-",9(!2$7!2%
Hardware shown at Actual Size
ABN (x2)
1/2” x 1/8” Spacer
AAE (x2)
5/16” x 1” Hex Bolt
AAO (x2)
5/16” Nylock Nut
BTS (x1)
1/4” Barrel Nut
ABD (x4)
5/16” Washer
BZO (x1)
1/4” x 3” Shoulder Bolt
"!#+"/!2$4/2)-!33%-",9(!2$7!2%
Hardware shown at Actual Size
0/,%4/"!3%!33%-",9(!2$7!2%
Hardware shown at Actual Size
ADS (x2)
1/4” x 3/4” Screw
!!& (x2)
3/8” Washer
ABB (x2)
3/8” Centerlock Nut
ABH (x2)
3/8” x 3 1/2” Hex Bolt
ADA (x2)
1/2” x 2.91” Spacer
CCL (x2)
3/16” Allen Wrench
CIH (x2)
Domed Countersink
Washer
AAS (x2)
1/4” x 2 3/4” Hex Bolt
ABC (x2)
5/16” x 1 1/4” Carriage Bolt
