Lifetime 51544 - Backboard and Rim Assembly

22
BACKBOARD TO RIM ASSEMBLY
SEC
3
Hardware shown at Actual Size
AAS (x2)
1/4” x 2 3/4” Hex Bolt
ABS (x2)
1/2” x 2 5/16” Galvanized Spacer
ABC (x2)
5/16” x 1 1/4” Carriage Bolt
ACS (x2)
.38” x 1” Steel Spacer
AAB (x2)
1/4” Centerlock Nut
!!* (x2)
v(EX4.UT
ABD (x2)
5/16” Washer
!"& (x2)
7/16” Rubber Washer
!"' (x2)
5/16” x 2 1/2” Tap Bolt
Hardware shown at 25% of Actual Size
ABK (x6)
5/16” Nylock Flange Nut
!*7 (x2)
Compression Spring
AOU (x1)
v5"OLT
!/7 (x1)
Spring Retainer Plate
AAV (x2)
5/16”Jam Nut
HARDWARE REQUIRED
