Lifetime 51544 - Handle Assembly

34
AAN (x1)
5/16” Cap Nut
AAL (x1)
1/4” x 1 1/4” Hex Bolt
!$' (x1)
1/2” x 6 5/8” Hex Bolt
6 5/8”
(Not actual length)
(Not actual length)
6 1/2”
ABA (x1)
3/8” x 6 1/2” Hex Bolt
AAM (x1)
5/16” x 1 1/2” Tap Bolt
AAX (x1)
1/2” Centerlock Nut
AAU (x1)
1/4” Cap Nut
ABB (x1)
3/8” Centerlock Nut
AAP (x2)
#6 x 3/8” Phillips
Pan Head Screw
ADT (x7)
#6 x 5/8” Screw
ACZ (x2)
.69” x 1.4” Spacer
AQH (x1)
Trigger Spring
!1' (x1)
,OCK4AB
HANDLE ASSEMBLY
HARDWARE REQUIRED
SEC
5
Hardware shown at Actual Size
