PARTS LIST
ID Item Description Qty
!,( Top Pole 1
!,& Middle Pole 1
!,% Bottom Pole 1
AJK Right Backboard Bracket 1
AJJ ,EFT"ACKBOARD"RACKET 1
AJI Backboard 1
!,8 Rim 1
AKZ Net 1
AJY Counterbalance Spring 1
AKC Short Extension Arm 2
AKB ,ONG%XTENSION!RM 2
!," Outer Tube 1
AKQ Inner Channel 1
AMN Trigger 1
!+, ,EFT(ANDLE 1
AKN Right Handle 1
!,, Pole Bracket 1
!,$ Plastic Guard 1
AJM Base 1
!,) Pole Brace 2
AMU Wheel 2
AJC 1/2” x 15 3/4” Axle 1
AJE 1/2” x 7” Axle 1
AEF Base Plug 2
!,. Pole Pad 1
!*8 Corner Frame Pad 2
AJQ Center Frame Pad 1
AKP Height Sticker (not shown) 1
AMT Warning Sticker (Applied to Middle Pole) 1
HARDWARE LIST
ID Item Description Qty
Pole Assembly Hardware (1066288)
ADS 1/4” x 3/4” Screw 2
ABH 3/8” x 3 1/2” Hex Bolt 2
ADA 1/2” x 2.91” Spacer 2
AAF 3/8” Washer 2
ABB 3/8” Centerlock Nut 2
CIH Domed Countersink Washer 2
Pole to Base Assembly Hardware (1066284)
AAO 5/16” Nylock Nut 2
ABD 5/16” Washer 4
AAE 5/16” x 1” Hex Bolt 2
ABN 1/2” x 1/8” Spacer 2
