Lifetime 51544 - Backboard to Pole Connection

29
BACKBOARD TO POLE ASSEMBLY
HARDWARE REQUIRED
PARTS REQUIRED
TOOLS REQUIRED
SEC
4
Parts shown at 10% of Actual Size
Hardware shown at Actual Size
Rubber Mallet
v7RENCH(x2)
AAX (x4)
1/2” Centerlock Nut
ABL (x4)
.69” x .59” Black
Spacer
!$' (x4)
1/2” x 6 5/8” Hex Bolt
ABP (x4)
1/2” x 3/8” Clear
Poly Spacer
6 5/8”
(Not actual length)
15 3/4”
AKC (x2)
Short Extension Arm
26”
AKB (x2)
,ONG%XTENSION!RM
!*9 (x1)
Counterbalance Spring
Part shown at 25% of Actual Size
v7RENCH(x2)
