Lifetime 51544 - Backboard to Pole Assembly Hardware

12
HARDWARE IDENTIFIER
AAB (x2)
1/4” Centerlock Nut
!"' (x2)
5/16” x 2 1/2” Tap Bolt
"!#+"/!2$4/2)-!33%-",9(!2$7!2%#/.4).5%$
Hardware shown at Actual Size
Hardware shown at 25% of Actual Size
!*7 (x2)
Compression Spring
AOU (x1)
v5"OLT
!/7 (x1)
Spring Retainer Plate
"!#+"/!2$4/0/,%!33%-",9(!2$7!2%
Hardware shown at Actual Size
AAX (x4)
1/2” Centerlock Nut
ABL (x4)
.69” x .59” Black
Spacer
!$' (x4)
1/2” x 6 5/8” Hex Bolt
ABP (x4)
1/2” x 3/8” Clear
Poly Spacer
6 5/8”
(Not actual length)
!!* (x2)
v(EX4.UT
ABD (x2)
5/16” Washer
!"& (x2)
7/16” Rubber Washer
ABK (x6)
5/16” Nylock Flange Nut
ABS (x2)
1/2” x 2 5/16” Galvanized Spacer
ACS (x2)
.38” x 1” Steel
Spacer
AAV (x2)
5/16”Jam Nut
