15
TOOLS AND HARDWARE REQUIRED FOR THIS PAGE
ALH
!,&
ADS
Align the hole in the Top Pole (ALH) with the slot in the -IDDLE0OLE!,& and
slide the Top Pole over the Middle Pole. Insert a 1/4” x 3/4” Screw (ADS)
through a $OMED#OUNTERSINK7ASHER#)( and into the small hole in the Top
Pole and into the slot in the Middle Pole as shown.
SEC
1.1
ADS (x1)
ALH
!,&
7ARNING
3TICKER
CIH (x1)
CIH
Note: The 1/4” x 3/4” Screw and Domed Countersink Washer
should be fl ush with the Pole, but will spin freely once installed.
Do not jam the Poles together until instructed.
!
