Lifetime 51544 - Page 16

16
TOOLS AND HARDWARE REQUIRED FOR THIS PAGE
Align the hole in the -IDDLE0OLE!,& with the slot in the Bottom Pole (ALE)
and slide the Middle Pole over the Bottom Pole. Insert a 1/4” x 3/4” Screw
(ADS) through a $OMED#OUNTERSINK7ASHER#)( and into the small hole in the
Middle Pole and into the slot in the Bottom Pole as shown.
SEC
1.2
!,&
ALE
ADS
!,&
ALE
ADS (x1)
CIH (x1)
CIH
Note: The 1/4” x 3/4” Screw and Domed Countersink Washer
should be fl ush with the Pole, but will spin freely once installed.
Do not jam the Poles together until instructed.
!
