Lifetime 51544 - Page 17

17
TOOLS AND HARDWARE REQUIRED FOR THIS PAGE
Insert the 3/8” x 3 1/2” Hex Bolts (ABH) with the v&LAT7ASHERS!!& into
the -IDDLE0OLE!,& as shown. Then slide the 1/2” x 2.91” Spacers (ADA)
onto the Hex Bolts. Place the 0OLE"RACKET!,, onto the 3/8” x 3 1/2”
Hex Bolts, and attach it to the Middle Pole with the hardware shown.
SEC
1.3
!,&
9/16” (x2)
!!& (x2)
ABB (x2)
ABH (x2)
ADA (x2)
!,&
ABH
ADA
!!&
ABB
ALL
Large holes
Small holes
