Lifetime 51544 - Page 30

30
TOOLS AND HARDWARE REQUIRED FOR THIS PAGE
Place one end of the #OUNTERBALANCE3PRING!*9 over the lower
vXv'ALVANIZED3PACER!"3 as shown.
SEC
4.1
Note: It may be necessary to use a Rubber Mallet to snap the Counterbalance Spring into
place. If the Rubber Mallet does not work , undo the hardware in the image that has been
shaded gray. Slide the Counterbalance Spring over the Spacer after it has been detached.
Then replace and re-secure the hardware.
!
!*9
ABS
./(!2$7!2%2%15)2%$&/24()30!'%
7/16” (x2)
