HANDLE ASSEMBLY
SEC
5
PARTS REQUIRED
Parts shown at 10% of Actual Size
v7RENCH(x2)
v7RENCH (x2)
TOOLS REQUIRED
Phillips Screwdriver
v7RENCH(x2)
v7RENCH(x2)
AMN (x1)
Trigger
AKL (x1)
,EFT(ANDLE
AKN (x1)
Right Handle
40”
33 1/3”
AKQ (x1)
Inner Channel
ALB (x1)
Outer Tube
Parts shown at 25% of Actual Size
