TOOLS AND HARDWARE REQUIRED FOR THIS PAGE
AAP (x2)
!1' (x1)
SEC
5.1
Secure the ,OCK4AB!1' to the Trigger (AMN) with the hardware shown.
Note: Make sure the Lock Tab is oriented as
shown when attaching the Tab to the Trigger.
!
AAP
AAP
!1'
AMN
SEC
5.2
Place the Right Handle (AKN) onto the Outer Tube (ALB) so that the notch
of the Outer Tube fi ts within the Handle as shown.
AKN
ALB
Note: Make sure that the Inner Channel (AKQ) has been
removed from the Outer Tube before performing this step.
!
