BACKBOARD TO RIM ASSEMBLY
SEC
3
PARTS REQUIRED
!*) (x1)
Backboard
ALX (x1)
Rim
!** (x1)
,EFT"ACKBOARD"RACKET
!*+ (x1)
Right Backboard Bracket
Parts shown at 10% of Actual Size
Part shown at 5% of Actual Size
Pliers
v7RENCH
v7RENCH (x2)
TOOLS REQUIRED
ALD (x1)
Plastic Guard
Part shown at 25% of Actual Size
