Lifetime 51544 - Page 41

41
TOOLS AND HARDWARE REQUIRED FOR THIS PAGE
SEC
5.9
Insert the 3/8” x 6 1/2” Hex Bolt (ABA) through the holes in the Short Extension
Arms (AKC) that are closest to the Pole. Secure the 3/8” x 6 1/2” Hex Bolt
to the Short Extension Arms with the v#ENTERLOCK.UT!"".
Note: Tighten the 3/8” Centerlock Nut until it is fl ush with the end of the Bolt.
!
(Not actual length)
6 1/2”
ABA (x1)
ABB (x1)
9/16” (x2)
ABA
ABB
AKC
AKC
