11 in.
(0,27 m)
3.8 in.
7 in.
(0,17 m)
Dimensions
Specifications
Maximum flow 10 gal./min. (38 l/min.)
Minimum flow 0.25 gal./min. (1 l/min.)
Operating pressure (maximum) 1,000 psi (69 bar)
Operating pressure (minimum) 5 psi (0,35 bar)
Operating temperature (maximum) 120 °F (50 °C)
Operating temperature (minimum) 20 °F (–5 °C)
Accuracy – oils ± 0.5%
5 digit LCD display, Quarts, pints, gallons, liters
Compatible fluids motor oil, gear oil, automatic
transmission and hydraulic
fluid
Inlet and outlet connections
1
/2 in. NPT
Minimum and maximum flow range Varies with fluid viscosity
Do not use unit with flammable liquids.
DANGER
14
