Meter installation
Relieve system pressure
1 Turn off the power supply to the pump or
close the shutoff valve.
2 Dispense any fluid in the system into a
waste container by opening the meter(s).
3 Open all bleed-type master air valves and
fluid meter(s) in the system.
4 Leave the meter(s) open until ready to
pressurize the system.
Pressurized equipment
Do not clean, service or inspect any part
of meter while pressurized.
Equipment stays pressurized
until pressure is manually relieved. To
reduce risk of injury from fluid spray,
follow pressure relief procedures when:
• instructed to relieve pressure
• stop dispensing
• check, clean or service any system
equipment
• clean or install nozzles.
WARNING
Explosion and Fire
Do not operate this meter without
correct grounding.
Movement of fluids through the
dispensing system creates static
electricity. Static electricity can ignite
volatile fumes resulting in an explosion
and fire.
Failure to comply may result in
serious injury or death.
WARNING
!
Notice
If installation is new or if fluid in
lines is contaminated, flush system
before installing meter(s).
!
Notice
If the system has multiple
dispense positions, begin at the position
farthest from the pump and move
toward the pump.
Flushing procedure
1 Close fluid dispense valves at every
position.
2 Once the main fluid outlet valve at the
pump is closed, the air pressure to the
pump motor is properly adjusted and the
air valve is opened.
3 Slowly open the main fluid valve.
4 Place the hose end in a waste container.
Make sure hose is secure so no fluid leaks
during flushing.
5 Slowly open the dispense valve and allow
enough oil to pass through it to ensure
that the system is clean.
6 Close the valve and repeat for all dispense
positions.
Grounding
1 Grounding reduces the risk of static
sparking. Ground all system components
according to local, state, and federal
codes. Consult the pump user’s manual
and other system components to ground
the following:
2 Pump: follow manufacturer’s
recommendations.
3 Air and fluid hoses: use only grounded
hoses.
4 Air compressor: follow manufacturers
recommendations.
5 Fluid supply container: follow the local
code.
7
