Meter hazards
Equipment misuse can cause the meter
to rupture or malfunction and cause
serious injury.
• This equipment is for professional use
only.
• Read all instructions, tags, and labels
before operating the equipment.
• Use the equipment only for its
intended purpose.
• Do not modify or alter the equipment.
• Do not leave equipment unattended
while dispensing.
• Check equipment daily. Repair or
replace worn or damaged parts
immediately.
• Do not exceed the maximum working
pressure level of the lowest rated sys-
tem component.
• Use only extensions and nozzles that
are designed for use with this
equipment.
• Use only fluids and solvents that are
compatible with the equipment.
Read all fluid and solvent manufac-
turer’s warnings.
• Tighten all fluid connections before
operating this equipment.
• Do not stop or deflect leaks with
hands, body gloves or rags.
• Do not dispense towards any person
or any part of the body.
• Do not place hands or fingers over
the end of or into the dispense valve.
• Comply with all local, state and federal
fire, electrical and safety regulations.
• Use of this product in a manner other
than specified in this manual may re-
sult in impaired operation or damage
to equipment.
WARNING
This meter is not designed to dispense
petroleum products or methanol based
windshield wiper fluid. This meter is
designed for windshield wiper fluid,
brake fluid, or water-based solutions.
WARNING
General
The electronic preset meter (EPM) is
designed specifically to meter and dispense
bulk fluids for servicing automobiles, trucks,
buses, construction equipment, and similar
applications. The meter is lightweight, rug-
ged and has a comfortable grip. The
meter is designed specifically to dispense
motor oils (S.A.E.5-50), gear oils
(S.A.E. 80-240), automatic transmission
fluid, and hydraulic fluid.
A superior rugged, shock-resistant design
for demanding environments.
Meter is not for resale measurement of
fluid.
Operation
This unit can be programmed to dispense in
quarts, liters, pints, and gallons. You can
program any batch size in a matter of sec-
onds. A 5-digit liquid crystal display, accu-
rate to the second decimal point, shows the
exact amount of fluid dispensed.
The EPM meter uses 4 replaceable AA
batteries and is calibrated at the factory.
The meter can also be recalibrated easily in
the field.
Electronic accuracy will help you save
time and money. The preset feature will
allow users to perform other service tasks
while fluid is dispensed.
Typical applications
• Fleet maintenance shops
• Industrial assembly
• Quick lube facilities
• Dealerships
• Construction and mining equipment
• General automotive service centres
• Specialty service and repair shops
Features and
specifications
• Oval gear driven meter
• Durable, rugged design
• Rubber boot
• Large, easy-to-read LCD display
• Ease of operation
• CE approved
• Totalization in liters and gallons
• Delivery in liters, quarts, pints, gallons
• Automatic non-drip nozzle with manual
shut-off feature
• Maximum totalizer number: 99,999 gal-
lons or liters
• Maximum dispense volume: 99,999 units
• Maximum preset volume: 99.9 Units
• Calibration factor for different fluids
• Changeable units of measure
• One programmable preset
• Total and re-settable total
• Minimum 20,000 cycles on battery life
• Low battery indicator
• Low battery safety lock out feature
• Uses standard AA batteries
• In-line swivel standard with all meters
• Automatic shut-off at preset amount
• Emergency manual shut-off
• Precision control valve operation
!
Notice
The automatic nozzle requires
60 psi (4,1 bar) to open and function
properly. A pump exceeding 60 psi
(4,1 bar) is required for adequate flow
and proper operation. A pump ratio of at
least 3:1 is recommended.
