Service
Low battery
When the batteries need to be changed a
progression of warnings appears on the
meter screen.
First Warning: the low battery icon appears
in the lower left corner of the display.
Change the batteries.
Second warning: battery icon flashes.
The battery power is too low and meter
functions are disabled.
Low battery icon
Changing the Batteries
The battery compartment is located in the
lower case on the underside of the trigger
guard.
1 Turn the unit over.
2 Unscrew the two screws. Remove the
battery door to expose the batteries.
3 Replace the old batteries.
!
Notice
Battery polarity markings are
inside battery compartment.
Meter takes 4 AA, alkaline, batteries.
4 Dispose of used batteries properly,
according to local regulations.
!
Notice
Changing batteries does not affect
any programmed values or totals.
Emergency override
In case of an emergency or to interrupt a
batch, the meter is equipped with an emer-
gency override.
1 Press the red stop button to activate the
emergency override. The override closes
the valve, immediately stopping fluid flow.
2 Batching can continue after an
emergency override by pulling up on the
trigger.
Error code
SF0 (scale factor 0) The scale factor setting
for the meter is 0.000.
• You must set a non-zero value to properly
measure fluid being dispensed.
• To input a valid scale factor for the meter
follow the instructions in the “change fac-
tory settings” section of this manual.
All other error codes are for factory purpos-
es only.
To clear the meter, reset press .
10
