Lincoln FLEXTEC 450 - Connecting Ln-15(K1870-1) to the Flextec 450; Connecting Ln-15(K1871-1) to the Flextec 450

A-10
INSTALLATION
FLEXTEC™ 450
A-10
CONNECTING LN-15(K1870-1) TO THE FLEXTEC™ 450
14-PIN CONTROL CABLE K1819-XX
ELECTRODE
FLEXTEC™-450
WIRE FEEDER
LN-15
(K1871-1)
WORK
ELECTRODE
FLEXTEC™-450
WORK
WORK CLIP
WIRE FEEDER
LN-15
(K1870-1)
CONTROL SETTING
WELD MODE
WELD TERMINALS
REMOTE/LOCAL
VOLTMETER POLARITY
CV, CV-INNERSHIELD
OFF
LOCAL
PROCESS DEPENDENT
CONTROL SETTING
WELD MODE
WELD TERMINALS
REMOTE/LOCAL
VOLTMETER POLARITY
CV, CV-INNERSHIELD
OFF
REMOTE
PROCESS DEPENDENT
CONNECTING LN-15(K1871-1) TO THE FLEXTEC™ 450
