Lincoln FLEXTEC 450 - Physical Dimensions; Temperature Ranges; Welding Process

A-2
INSTALLATION
FLEXTEC™ 450
A-2
PHYSICAL DIMENSIONS
TEMPERATURE RANGES
HEIGHT
18.80in (478mm)
MODEL
K2882-2
WIDTH
14.14in (359mm)
DEPTH
26.66in (677mm)
WEIGHT
125lbs (56.6kg)*
OPERATING TEMPERATURE RANGE
Environmentally Hardened: 14°F to 131°F (-10°C to 55°C
**
)
STORAGE TEMPERATURE RANGE
Environmentally Hardened: -40°F to 185°F (-40°C to 85°C)
PROCESS
GMAW (CV)
GTAW (CC)
SMAW (CC)
FCAW-GS (CV)
FCAW-SS (CV)
OUTPUT RANGE (AMPERES)
40-500
10-500
15-500
40-500
40-500
OCV (Uo)
60
24
60
60
60
WELDING PROCESS
IP23 155º(F) Insulation Class
* Weight does not include input cord.
** Output De-rated at Temperatures above 40°C.
