Case Front Assembly (G6447), Includes: NSS 1X•
Case Front Assembly (G6447-4), Includes: NSS 1•X
1 Case Front G6456 1 X •
1 Case Front G6456-1 1 • X
2A Output Stud M22515 2 X X
2B Plain Washer (Not Shown) S9262-98 8 X X
2C 1/4-20 x 1.00 HHCS (Not Shown) CF000015 4 X X
2D Lock Washer (Not Shown) E106A-2 4 X X
2E 1/4-20 HN (Not Shown) CF000017 4 X X
3A Line Switch (Part of Line Switch & Lead Asbly) S20030 1 X X
3B Switch Cover S25384-1 1 X X
3C #6-32 x .75 RHS (Not Shown) CF000137 2 X X
3D Lock Washer (Not Shown) T9695-2 2 X X
4
Nameplate (Display Decal) (G6762-1) (Part of G6762) NSS 1X•
4 Nameplate (Display Decal) (G7539-1) (Part of G7539) NSS 1•X
5A Circuit Breaker T12287-20 1 X X
5B Sealing Boot S22061-3 1 X X
6 Toggle Switch (2 Position) T10800-4 3 X X
7 Toggle Switch (2 Position) T13562-1 1 X X
8A LED Lens, Includes: S23093-1 1 X X
8B Retaining “O” Ring S23094-1 1 X X
9 Main Control Harness, Includes: G6897 1 X X
9A Connector (14 Socket) S12021-70 1 X X
9B Connector (6 Socket) S12021-68 1 X X
9C Self Tapping Screw (Not Shown) S8025-96 4 X X
9D Cap S17062-10 1 X X
9E Cap S17062-11 1 X X
10 Potted Control Harness (Not Shown), Includes: L15824-1 1 X X
R2 & R3 Potentiometers, Rotary Switch & LED
11 Meter Board Assembly L10952-[ ] 1 X X
12 Knob (Large) T10491 1 X X
12A “O” Ring (Not Shown) T13483-34 1 X X
13 Knob (Small) T13639-3 2 X X
13A “O” Ring (Not Shown) T13483-34 2 X X
14A Handle G6525-1 1 X •
14A Handle G6525-3 1 • X
14B Handle Support Bracket M22463-1 1 X •
14B Handle Support Bracket M22463-2 1 • X
14C Self Tapping Screw S9225-66 4 X X
15 Noise Suppressor Assembly (Not Shown) S28393 1 X •
15 Noise Suppressor Assembly (Not Shown) S28393-1 1 • X
16 Sealing Boot S22061-4 4 X X
20 Self Tapping Screw (Not Shown) S9225-68 2 X X
21A Door G6879 1 X X
21B Plain Washer (Not Shown) S9262-27 1 X X
21C #10-24 HLN (Not Shown) T9187-13 1 X X
22 Output Door Decal (G6762-2) (Part of G6762) NSS 1X•
22 Output Door Decal (G7539-2) (Part of G7539) NSS 1•X
24A 3/8-16 x 1.50 Carriage Bolt T11827-67 2 X X
24B 3/8-16 HN (Not Shown) CF000067 2 X X
08-15-2012
FLEXTEC
™
450
Use only the parts marked “x” in the column under the
heading number called for in the model index page.
# Indicates a change this printing.
P-652-C.1
ITEM DESCRIPTION PART NO. QTY. 123456789
P-652-C.1
NSS - Not Sold Separately
