Lincoln FLEXTEC 450 - Page 49

Divider Panel Assembly, (G6458), Includes: NSS 1 XXX
1 Divider Panel G6459 1 X X X
3A Rectifier Module T13637-6 1 X X X
3B Thread Forming Screw (Not Shown) S9225-94 1 X X X
4 Input Rectifier Assembly, Includes: NSS 1 XXX
4A Input Rectifier M15454-16 1 X X X
4B Plain Washer (Not Shown) S9262-98 2 X X X
4C Lock Washer (Not Shown) E106A-2 2 X X X
4D 1/4-20 x .625 HHCS (Not Shown) CF000013 2 X X X
5A Auxiliary Transformer S13000-109 1 X X X
5B Plain Washer S9262-98 4 X X X
5C Thread Forming Screw S9225-65 4 X X X
6A Control Transformer M22500 1 X X X
6B Thread Forming Screw (Not Shown) S9225-94 2 X X X
7 Grommet T12380-4 2 X X X
8 Input Connection Decal S28388 1 X X X
9A Terminal Block S20763-3 2 X X X
9B #8-32 x 1.25 PNHS (Not Shown) CF000193 4 X X X
9C Lock Washer (Not Shown) T9695-3 4 X X X
9D #8-32 HN (Not Shown) CF000042 4 X X X
10A Control P.C. Board S28454-[ ] 1 X X X
10B Self Tapping Screw S9225-76 2 X X X
10C Speed Clip (Not Shown) T11525-1 2 X X X
11 Ground Decal T13260-4 1 X X X
13 Rubber Channel T11019-9 1 X X X
15 Self Tapping Screw (Not Shown) S9225-68 2 X X X
17 MOV Assembly S18491-1 1 X X X
20 Plug & Lead Assembly (Not Shown) S18250-987 1 • X •
20 Plug & Lead Assembly (Not Shown) S18250-995 1 • • X
21A Input P.C. Board Assembly M22618-[ ] 1 • X X
21B #10-24 HLN (Not Shown) T9187-13 2 • X X
22 Capacitor Board Mounting Bracket L15928 1 • X X
23A Resistor T8280 1 • X •
23B Plain Washer (Not Shown) S9262-27 2 • X •
23C Mounting Washer T9764-6 2 • X •
23D #10-24 x 5.00 RHS CF000045 1 • X •
23E Lock Washer (Not Shown) E106A-1 1 • X •
23F #10-24 HN (Not Shown) CF000010 1 • X •
24A Fuse Holder T12386 1 • X X
24B #8-32 x .50 RHS CF000033 2 • X X
24F Fuse (Not Shown) T10728-65 2 • X X
25 Fuse Decal (Not Shown) S28633 1 • X X
08-15-2012
FLEXTEC
™
450
Use only the parts marked “x” in the column under the
heading number called for in the model index page.
# Indicates a change this printing.
P-652-D.1
ITEM DESCRIPTION PART NO. QTY. 123456789
P-652-D.1
Note: When ordering new printed circuit boards indicate the dash number [ ] of the “Old” board
that is to be replaced. This will aid Lincoln in supplying the correct and latest board along
with any necessary jumpers or adapters. The dash number brackets [ ] have purposely
been left blank so as to eliminate errors, confusion and updates.
NSS - Not Sold Separately
