Lincoln FLEXTEC 450 - Page 51

Base & Center Assembly, Includes: G6490 1 X •
Base & Center Assembly, Includes: G6490-4 1 • X
1 Base G6446 1 X X
2A Corner Cap L13138 4 X X
2B Plain Washer S9262-183 6 X X
2C Self Tapping Screw S9225-66 6 X X
3A Mounting Washer T9764-6 2 X X
3B Resistor S10404-118 1 X •
3B Resistor S10404-139 1 • X
3C Thru Bolt (Not Shown) T9781-34 1 X •
3C Carriage Bolt (No Shown) T11827-59 2 • X
3D Plain Washer S9262-98 2 X X
3E Lock Washer E106A-2 2 X X
3F 1/4-20 HN CF000017 2 X X
6A Shunt S6602-30 1 X X
6B Carriage Bolt T11827-26 1 X X
6C Plain Washer (Not Shown) S9262-30 1 X X
6D Lock Washer (Not Shown) E106A-3 1 X X
6E 5/16-18 HN (Not Shown) CF000029 1 X X
7A Thread Forming Screw S9225-95 2 X X
7B Plain Washer (Not Shown) S9262-27 2 X X
7C Lock Washer (Not Shown) E106A-1 2 X X
7D #10-24 HN (Not Shown) CF000010 2 X X
8A Choke Assembly L15821 1 X X
8B Thread Forming Screw S9225-66 4 X X
8C Plain Washer S9262-98 4 X X
Connects Choke Coil to Output Stud:
9A Carriage Bolt (Not Shown) T11827-26 1 X X
9B Plain Washer (Not Shown) S9262-30 1 X X
9C Lock Washer (Not Shown) E106A-3 1 X X
9D 5/16-18 HN (Not Shown) CF000029 1 X X
10A Output Rectifier Sub Assembly L15816 1 X X
10B Self Tapping Screw (Not Shown) S9225-68 2 X X
11A Transformer Assembly G6453 1 X X
11B Self Tapping Screw (Not Shown) S9225-68 4 X X
13A 5/16-18 x 1.25 HHCS CF000028 2 X X
13B Plain Washer (Not Shown) S9262-30 4 X X
13C Lock Washer (Not Shown) E106A-3 2 X X
13D 5/16-18 HN CF000029 2 X X
15A Switch Board Assembly G6491 1 X •
15A Switch Board Assembly G7485 1 • X
15B Self Tapping Screw S9225-65 2 X X
08-15-2012
FLEXTEC
™
450
Use only the parts marked “x” in the column under the
heading number called for in the model index page.
# Indicates a change this printing.
P-652-E.1
ITEM DESCRIPTION PART NO. QTY. 123456789
P-652-E.1
NSS - Not Sold Separately
