1A Case Side (Left) G6450 1 X X X
1B Nut Retainer (Not Shown) T10097-3 2 X X X
1C Self Tapping Screw S9225-68 6 X X X
1D Self Tapping Screw S9225-66 4 X X X
1E Plain Washer (Not Shown) S9262-183 4 X X X
1F Case Side (Right) G6451 1 X X X
2A Roof G6452 1 X X X
2B Self Tapping Screw (Not Shown) S9225-68 8 X X X
5 Wiring Diagram G6890 1 X • •
5 Wiring Diagram G6890-1 1 • X •
5 Wiring Diagram G6890-5 1 • • X
6 Warranty Decal S22127-2 1 X X X
7 Green Initiative Decal S28039-2 1 X X X
8 Lincoln Logo Decal S27368-4 2 X X X
9 Flextec Decal M22461 2 X X X
10 Warning Decal M16196 1 X X X
08-15-2012
FLEXTEC
™
450
Use only the parts marked “x” in the column under the
heading number called for in the model index page.
# Indicates a change this printing.
P-652-G.1
ITEM DESCRIPTION PART NO. QTY. 123456789
