Lincoln FLEXTEC 450 - Page 61

Case Front Assembly (G6447-4), Includes: NSS 1X
1 Case Front G6456-1 1 X
2 Nameplate (Display Decal) (G7539-1) (Part of G7539) NSS 1X
3A Handle G6525-3 1 X
3B Handle Support Bracket M22463-2 1 X
3C Self Tapping Screw S9225-66 4 X
4A Output Stud M22515 2 X
4B Plain Washer (Not Shown) S9262-98 8 X
4C 1/4-20 x 1.00 HHCS (Not Shown) CF000015 4 X
4D Lock Washer (Not Shown) E106A-2 4 X
4E 1/4-20 HN (Not Shown) CF000017 4 X
5A Line Switch (Part of Line Switch & Lead Asbly) S20030 1 X
5B Switch Cover S25384-1 1 X
5C #6-32 x .75 RHS (Not Shown) CF000137 2 X
5D Lock Washer (Not Shown) T9695-2 2 X
6A Circuit Breaker T12287-20 1 X
6B Sealing Boot S22061-3 1 X
7 Toggle Switch (2 Position) T10800-4 3 X
8 Toggle Switch (2 Position) T13562-1 1 X
9A LED Lens, Includes: S23093-1 1 X
9B Retaining “O” Ring S23094-1 1 X
10 Main Control Harness, Includes: G6897 1 X
10A Connector (14 Socket) S12021-70 1 X
10B Connector (6 Socket) S12021-68 1 X
10C Self Tapping Screw (Not Shown) S8025-96 4 X
10D Cap S17062-10 1 X
10E Cap S17062-11 1 X
11 Potted Control Harness (Not Shown), Includes: L15824-1 1 X
R2 & R3 Potentiometers, Rotary Switch & LED
12 Meter Board Assembly L10952-[ ] 1 X
13 Knob (Large) T10491 1 X
13A “O” Ring (Not Shown) T13483-34 1 X
14 Knob (Small) T13639-3 2 X
14A “O” Ring (Not Shown) T13483-34 2 X
15 Noise Suppressor Assembly (Not Shown) S28393-1 1 X
18 Sealing Boot S22061-4 4 X
19 Plug & Lead Assembly (Not Shown) S18250-994 1 X
23 Self Tapping Screw (Not Shown) S9225-68 2 X
24A Door G6879 1 X
24B Plain Washer (Not Shown) S9262-27 1 X
24C #10-24 HLN (Not Shown) T9187-13 1 X
25 Output Door Decal (G7539-2) (Part of G7539) NSS 1X
26A 3/8-16 x 1.50 Carriage Bolt T11827-67 2 X
26B 3/8-16 HN (Not Shown) CF000067 2 X
26C Plain Washer (Not Shown) S9262-120 2 X
26D Lock Washer (Not Shown) E106A-16 2 X
02-04-2013
FLEXTEC
™
450
Use only the parts marked “x” in the column under the
heading number called for in the model index page.
# Indicates a change this printing.
P-732-C.1
ITEM DESCRIPTION PART NO. QTY. 123456789
P-732-C.1
Note: When ordering new printed circuit boards indicate the dash number [ ] of the “Old” board
that is to be replaced. This will aid Lincoln in supplying the correct and latest board along
with any necessary jumpers or adapters. The dash number brackets [ ] have purposely
been left blank so as to eliminate errors, confusion and updates.
NSS - Not Sold Separately
