Lincoln Impinger - Sequence of Operations

CounterTop – 1300 Series Service Manual
3
SEQUENCE OF OPERATIONS
MODEL CTI
1300 200 VAC 60 HZ 1 PHASE
1301 208 VAC 60 HZ1 1 PHASE
1302 240 VAC 60 HZ 1 PHASE
1303 220 VAC 50 HZ 1 PHASE
1304 240 VAC 50 HZ 1 PHASE
1305 380/220 VAC 50 HZ 1 PHASE
1306 415/240 VAC 50 HZ 1 PHASE
1307 200 VAC 60 HZ 3 PHASE
1308 380/220 VAC 50 HZ 3 PHASE
1309 415/240 VAC 50 HZ 3 PHASE
1310 220 VAC 60 HZ 1 PHASE
1311 380/220 VAC 60 HZ 3 PHASE
1312-000-E 400/230 VAC 50 HZ 3 PHASE
1313-000-E 400/230 VAC 50 HZ 2 PHASE
1314-F24-E 240 VAC 50 HZ 1 PHASE
POWER SUPPLY
(Electrical power supplied to the oven:)
1300/1301/1302 1303/1304/1314-F24-E 1305/1306
Black – Hot
Red – Hot
Green - Ground
Brown - Hot
Blue – Neutral
Green/Yellow-Ground
Brown – Hot
Black – Hot
Blue – Neutral
Green/Yellow-Ground
1307 1308/1309/1311 1310
Red – Hot
Black - Hot
Orange – Hot
Green - Ground
Brown – Hot
Black (2) – Hot
Blue – Neutral
Green/Yellow – Ground
Brown – Hot
Black – Hot
Green/Yellow-Ground
1312-000-E 1313-000-E
Black (3) – Hot
Blue – Neutral
Green/Yellow – Ground
Black (2) – Hot
Blue – Neutral
Green/Yellow - Ground
