Lincoln Impinger - Control Compartment - 1300 Series

CounterTop – 1300 Series Service Manual
56
CONTROL COMPARTMENT – 1300 SERIES
LETTER P/N DESCRIPTION
A 369426 Cooling Fan – S/N 3000399 & Below
369378 Cooling Fan – S/N 3000400 & Above
B 369428 Finger Guard – S/N 3000399 & Below
369331 Finger Guard – S/N 3000400 & Above
C 369415 Conveyor Control S/N 3000480 & Below
369464 Conveyor Control – S/N 3000481 to 3007663
Except Models 1301-5, 1302-5, 1304-5, 1308-5
370017 Conveyor Control S/N 3007664 and Above and
All S/N for Models 1301-5, 1302-5, 1304-5, 1308-5
D 369431 Thermostat, Control Box Hi-Limit S/n 3000352 & Above
E 369430 Air Switch – S/N 3043630 & Below
F 369422 Relay SPST, 240V
G 369417 Time Delay Relay
H 369425 Relay Contactor Single Phase
369479 Relay Contactor 3 Pole 3 Phase
I 369427 Transformer, Conveyor Control
370241 Transformer, Conveyor Control Models 1312,1313,1314
J 369416 Electronic Temperature Control S/N 3000480 & Below
369465 Electronic Temperature Control S/N 3000481 & Above
K 369129 Fuse Holder, Model 1300,1301,1302,1307
L 369424 Conveyor Drive Motor S/N 3000480 & Below
369923 Conveyor Motor Assy. Models 1301-5,1302-5,1304-5,1308-5
369466 Conveyor Motor Assy (Assy. Includes Q,R)
S/N 3000481 & Above Except 1301-5,1302-5,1304-5,1308-5
369841 Brushes (For 369466 Motor)
M 369154 Circuit Breaker - .7Amp
357067 Thermostat, Capillary
N
4030184 Thermostat, Capillary (CE models)
O 369483 Housing Assy.
P 369482 Fan Housing
Q 369822 Magnet, 8 Pole (For 1-12 Minute Conveyor System)
370065 Magnet, 16 Pole (For 1-24 Minute Conveyor System)
R 369823 Hall Effect Sensor
S 369421 Fuse 5A, Model 1300,1301,1302,1307
T 370100 Conveyor Motor Plate, Inner
U 370040 Hall Effect Cable
V 370099 Conveyor Motor Plate, Outer
W 369414 Power Cord 30A S/n 3007818 & Below (Model 1301,1302)
370019 Power Cord 50A S/N 3007819 & Above (Model 1301,1302)
X 369536 Cooling Fan Cordset
Y 369085 Junction Box
Z 369376 Terminal Block 3 Pole
369584 Terminal Block 4 Pole
AA 369698 Cover, Junction Box
BB 369856 Stand-off, Support
CC 357107 Fuseholder
DD 369492 Fuse 5A
EE 369131 Thermocouple
