Lincoln Impinger - General - 1300 Series

CounterTop – 1300 Series Service Manual
54
GENERAL – 1300 SERIES
LETTER P/N DESCRIPTION
A 369434 Air Duct Panel, Upper
B 369442 Finger Housing S/N 3002167 & Below
C 369436 Columnating Plate #2 (UR) – S/N 3002167 & Below
D 369445 Finger Cover, Upper Right – S/N 3002167 & Below
E 369441 Finger Cover, Lower Right – S/N 3002167 & Below
F 369439 Columnating Plate #4 (LR) – S/N 3002167 & Below
G 369435 Air Duct Panel, Lower
H 369438 Columnating Plate #3 (LL) – S/N 3002167 & Below
I 369444 Finger Cover, Lower Left – S/N 3002167 & Below
J 369446 Finger Cover, Upper Left – S/N 3002167 & Below
K 369437 Columnating Plate #1 (UL) – S/N 3002167 & Below
L 369916 Top / Front Cover Panel
M 369484 Cover Panel Assy
N 369407 Fastener & Split Ring Retainer (S/N 3046209 & Below)
369211 Thumb Screw (S/N 3046210 & Above)
O 369447 Cover Panel Assembly, Right
P 369953 Flat Washer, S/S
Q 369460 Compression Spring
R 369410 Coupling Sleeve
S 370106 Flat Washer, .156 x .430
T 350259 Screw, THMS 6-32 x 3/8
U 369413 Drive Key
V 369373 Receptacle, Snap-In
W 369461 Leg, 4”
X 369945 Control Panel
Y 369429 Knob, Control
Z 369432 Switch, On – Off
AA 369449 Temperature Control Pot. Assembly
BB 369433 Potentiometer Control, Conveyor S/N 3000480 & Below
369468 Potentiometer Control, Conveyor S/N 3000481 & Above
CC 350224 Lens, Yellow
DD 369448 Cover Panel Assembly, Left
EE 369467 Pilot Light & Harness – S/N 3000481 & Above
FF 369495 Conveyor Baffle
GG 369211 Thumb Screw
HH 369451 Mounting Ring Assy.
JJ 369491 Finger Cover – S/N 3002168 & Above (4 required)
KK 369490 Columnating Plate – S/n 3002168 & Above (4 required)
LL 369488 Finger housing – S/n 3002168 & Above (4 required)
MM 369932 Facia 1-12 Minute Bake Time
370096 Facia 2-24 Minute Bake Time
370018 Facia 1-24 Minute Bake Time
NN 370095 Control Guard
OO 370097 Screw 10-32 x ¼”
PP 370657 Finger Cover (S/N 3045308 & Above)
QQ 370658 Columnating Plate (S/N 3045308 & Above)
RR 369442 Finger Housing (S/N 3045308 & Above)
SS 370656 Lower Air Duct Panel (S/N 3045308 & Above)
TT 370655 Upper Air Duct Panel (S/N 3045308 & Above)
