CounterTop – 1300 Series Service Manual
61
EXTENDED CONVEYOR – 1300 SERIES
LETTER P/N DESCRIPTION
369909 Extended Conveyor Assy. (49 ¾” Length)
A 369462 Idler Axle
B 369515 Drive Sprocket
C 369516 Conveyor Bearing
D 369463 Drive Axle
E 369471 Roll Pin, 5/32 x 7/8”
F 369943 Conveyor Frame, Extended
G 369412 Conveyor Splice Clip
H 369481 Conveyor Belting – Extended Conveyor
370185 Conveyor Belting (1 Foot Section)
I 369920 Retainer
J 369921 Roller, Slider Bed
K 369954 Pop Rivet S/S
L 369922 Support Rod
M 1345 Pan Stop
N 369489 Crumb Pan Assembly
