CounterTop – 1300 Series Service Manual
60
STANDARD CONVEYOR – 1300 SERIES
LETTER P/N DESCRIPTION
369443 Standard Complete Conveyor Assy. (31” Length)
A 369462 Idler Axle
B 369515 Drive Sprocket
C 369516 Conveyor Bearing
D 369463 Drive Axle
E 369471 Roll Pin, 5/32 x 7/8”
F 1343 Entry Shelf – 12”
1344 Entry Shelf – 4”
G 369412 Conveyor Splice Clip
H 369411 Conveyor Belting
370185 Conveyor Belting (1 foot section)
I 1341 Exit Shelf – 12”
1342 Exit Shelf – 4”
J 370094 Conveyor Frame Assembly
