CounterTop – 1300 Series Service Manual
58
BACK – 1300 SERIES
LETTER P/N DESCRIPTION
Color Coded on The Cold Zone
A 369418 Heating Element - 208V Red
369419 Heating Element - 240V Blue
369450 Heating Element - 220V Yellow
369455 Heating Element - 200V Orange
369456 Heating Element - 380V Violet
370105 Heating Element - 400V 1 PH Brown
369457 Heating Element - 415V Green
369475 Heating Element - 200V 3 PH Orange
369476 Heating Element - 380V 3 PH Violet
370104 Heating Element - 400V 3 PH Brown
369477 Heating Element - 415V 3 PH Green
B 369409 Main Fan
C 369408 Air Pump
D 369440 Nut, S/S ¼ - 20
E 369192 Capacitor
F 369458 Nut, 10-32
G 370041 Duct Assy
H 370020 Motor Cover Assy
I 370102 Bottom Cap, Flue Duct
J 369453 Flue Duct Assembly
K 369423 Motor, Main Fan S/N 3002137 & Below – All 1301-4,1302-4
369485 Motor, Main Fan 60 Hz S/N 3002168 & Above
370179 Motor, Main Fan 50 Hz – Models 1304-4,1305-4,1308-4
369480 Motor, Main Fan 50 Hz S/n 3002168 & Above
L 369940 Motor Mount
M 370093 Motor Plate Assy
N 369474 Insulation, Air Pump Panel
O 369936 Plenum Barrier Panel
P 369473 Insulation, Plenum Panel
369935 Cover Plate, Plenum
Q
370728 Cover Plate, Plenum (For CE Units Only)
R 369470 Insulation Seal
S 369497 Bracket, Thermostat, Left Side
T 369496 Bracket, Thermostat, Right Side
U 369459 Motor Cover Assy
