36
D9U001AM2-0101_04
11.1.2 Infusion Stand
It is possible to insert infusion stands in the sockets at the head and foot ends of the bed.
Use exclusively infusion stands with 4 hooks for hanging IV bags or baskets for intravenous solutions.
Ensure that the infusion stand’s weight-bearing capacity is not exceeded.
Ensure that the weight-bearing capacity of the 4 hooks is not exceeded.
Capacity per hook: 2 kg
11.1.3 Accessory Rails
Load capacity:
Maximum load of 5 kg without leverage.
Maximum load of hook pair 10 kg.
Accessories for hanging on the accessory rail:
Cannula holder
Urine bag holder
Urine bottle basket
DIN steel bar
WARNING!
Risk of injury due to incompatible accessories!
Use infusion stands exclusively for accessories listed in the instructions for use.
Do not use infusion stands for hanging infusion pumps, dosing devices etc. as this equipment might
collide with movable parts of the bed.
Fig. 15 Accessory Rail
