18 Technical Specifications
18.1 Mechanical Specifications
* Depending on configuration
18.2 Environment Conditions
Environmental Conditions - Operation
 Temperature
 Humidity
 Atmospheric Pressure
10 °C — 40 °C
30 % — 75 %
795 hPa — 1060 hPa
Environmental Conditions - Storage and Transport
 Temperature
 Humidity
 Atmospheric Pressure
-20°C — 50°C
20% — 90% (non-condensing)
795 hPa — 1060 hPa
Dimensions
220 cm x 110 cm
Siderail Height Above Mattress Support Platform
48 cm
Side Rails Length
146 cm
Maximum Mattress Height
26 cm
Mattress Support Platform Dimensions (Mattress)
200 cm x 100 cm
Mattress Support Platform Extension
0 cm / 10 cm / 22 cm / 30,5 cm
Mattress Support Platform Height Adjustment
28 cm – 80 cm (85 cm*)
Undercarriage Clearance
13 cm (15,5 cm*)
Castor Diameter
12,5 cm
Maximum Backrest Angle
70°
Maximum Thighrest Angle
34°
Ergoframe®
10 cm / 6 cm
Trendelenburg
14°
Reverse Trendelenburg position
14°
Bed Weight
160 kg
Maximum Lifting Pole Load
100 kg
Safe Working Load (including Mattress and Accessories)
320 kg
Maximum patient weight
Application environment 1, 2
Application environment 3, 5
255 kg
285 kg
