13 Troubleshooting
Error/Fault
Cause
Solution
Adjusting with position buttons not
possible
GO button was not pressed
Press the GO button.
Function disabled on supervisor
control panel
Enable disabled function.
Drive motors have no power
Defective drive motors Defective
battery
Check the mains connection. Notify
the service department.
Plug inserted incorrectly
Insert the mains plug correctly.
Faulty power box
Notify the service department.
Faulty control element
Notify the service department.
Faulty mattress platform
height/tilt adjustment
There is an object on the
undercarriage cover
Remove the object.
Function disabled on supervisor
panel
Enable disabled function.
Drive motors have no power
Defective drive motors Defective
battery
Check the mains connection. Notify
the service department.
Plug inserted incorrectly
Insert the mains plug correctly.
Faulty power box
Notify the service department.
Faulty control element
Notify the service department.
Lowering backrest from the
upright position not possible
Object under the backrest or in
the drive mechanism
Remove the object.
Locking handle is defective
Notify the service department.
Adjusting side rails not possible
The side rail lock is dirty
Clean the locking mechanism.
Locking handle is defective
Notify the service department.
Faulty brakes
The brakes are blocked by dirt
Clean the brake system.
The brake mechanism is defective
Notify the service department.
Inserting head and foot boards not
possible
The head or foot board is in the
wrong position
Check the locking mechanism.
Position the head or foot board
correctly.
Defective mechanism
Notify the service department.
DANGER!
Danger to life due to electric shock!

If a fault occurs ensure the electric motor, power box and other electrical parts checked by qualified
personnel only.

Do not open protective covers of the electric motor or power box.
