18.4.1 Manufacturer’s Manual and Declaration - Electromagnetic Resistance
Resistance Test
Test Level as per
IEC 60601
Level of Compliance
Electromagnetic
Environment
Electrostatic
discharge (ESD)
IEC 61000-4-2
± 6 kV for contact
± 8 kV for air
± 6 kV for contact
± 8 kV for air
 Ensure that the
following requirements
are met: Floors: wood,
concrete or ceramic
tiles Relative
humidity: >30%
Electrical fast transient
response/
group of impulses
IEC 61000-4-4
± 2 kV in feeder line
± 1 kV in input/output
line
± 2 kV in feeder line
± 1 kV in input/output
line
 Ensure the mains
quality is suitable for a
commercial or hospital
environment.
Shock pulse
IEC 61000-4-5
± 1 kV between
lines
± 2 kV between line
(lines) and earth
± 1 kV in differential
mode
± 2 kV in co-phasal
mode
 Ensure the mains
quality is suitable for
commercial or hospital
environment.
Short-time voltage
drop, short-duration
interruptions
and slow voltage
changes on the feeder
input line
IEC 61000-4-11
<5 % UT
(>95 % short-duration
drop of UT)
within 0.5 cycles
40 % UT
(60 % short-duration
drop of UT)
within 5 cycles
70 % UT
(30 % short-duration
drop of UT)
within 25 cycles
<5 % UT
(>95 % short-duration
drop of UT)
within 5 s
<5 % UT
(>95 % short-duration
drop of UT)
within 0.5 cycles
40 % UT
(60 % short-duration
drop of UT)
within 5 cycles
70 % UT
(30 % short-duration
drop of UT)
within 25 cycles
<5 % UT
(>95 % short-duration
drop of UT)
within 5 s
 Ensure that mains
quality is suitable for a
commercial or hospital
environments.
 For permanent
operation during a
power failure, connect
the bed to a power
generator as the back-
up battery’s capacity is
limited.
Magnetic field of
network frequency
(50/60 Hz)
IEC 61000-4-8
3 A/m
3 A/m
 Ensure the magnetic
fields of the network
frequency conform to
the normal levels of
commercial or hospital
environments.
NOTE UT refers to the AC mains voltage before the test level is applied.
