M565Li OWNER’S/OPERATOR’S MANUAL
7. CONTROL AND PARTS FUNCTIONS
37
Brake Fluid Level
The brake fluid in the master cylinder, which is located on the left handlebar,
should be checked before each side. There is an indicator window (1) on the
side of the master cylinder. Fluid level can be seen through it, and should be
maintained between the “max” and “min” marks.
NOTE:
When checking the fluid level, the ATV must be on level ground and the
handlebars must be straight. If the fluid level is low, add DOT 4 only.
Seat
To avoid personal injury:
1.
Make sure that the seat is correctly secured.
2.
Do not allow any person other than the driver to ride on the ATV.
Brake lever
Side window
