M565Li OWNER’S/OPERATOR’S MANUAL
13. CVT SYSTEM
64
The CVT system rotates at high speeds, creating large amounts of force on
clutch components. However, as the owner you have the following
responsibilities to make sure this system remains safe:
Do not modify any component of the CAT system. Doing so may
reduce its strength so that a failure may occur at high speeds. Any
modification will cause the system to be out of balance, creating vibration
and additional loads on components.
Routine maintenance is the responsibility of the owner. Always follow
recommended maintenance procedures. See you dealer!
The CVT housing must be securely in place during operation.
Failure to comply with this warning can result in severe injury or death.
Low Range Use May Reduce CVT Operating Temperatures
The basic operation of the CVT system is dependent on engine speed and
torque requirements. As engine speed increased, the force exerted on the
movable drive sheave by the fly-weights also increases. This, in turn, increases
the amount of “pinch” applied to the drive belt. Similarly, if the engine revs
decrease, the amount of centrifugal; force decreases, reducing the amount of
belt “pinch”.
