M565Li OWNER’S/OPERATOR’S MANUAL
17. TROUBLESHOOTING
93
Issues of Improper Operation Driven Clutch (CVT) Burning
Possible Causes Solution
Loading the ATV into a
pickup or tall trailer when in
high range.
Shift transmission to Low Range during loading of the
ATV to prevent belt burning
Starting out going up a
steep incline
When starting out on an incline, use low range, or
dismount the ATV after first applying the park brake
and perform the “K- turn” as described in this manual.
Driving at low RPM or low
speed (at approximately
5-12 km/h）
Drive at higher speed or use low range. The use of low
range is highly recommended for cooler CVT operating
temperatures and longer component life.
Insufficient warm-up of
ATV’s exposed to low
ambient temperatures.
Warm engine at least 5 min., they with transmission in
neutral, advance throttle to approx. 1/8throttle in short
bursts, 5-7 times. The belt will become more flexible
and prevent belt burning.
Slow and easy clutch
engagement.
Fast, effective
engagement.
use of the throttle for efficient
Towing /Pulling at low RPM
/ low speed.
Use Low range only.
Stuck in mud or snow. Shift the transmission to Low Range carefully use fast,
aggressive throttle application to engage clutch.
WARNING: Excessive throttle may cause loss of
control and overturn.
Climbing over large objects
from a stopped position.
Shift the transmission to Low Range carefully use fast,
brief, aggressive throttle application to engage clutch.
WARNING: Excessive throttle may cause loss of
control and overturn.
Battery Issues
Possible Cause Solution
Starting a faulty engine for
long time
See ”8. STARTING THE ENGINE”. And
check the fuel/ air/ ignition/ compression
system
Let the main switch (key)
while parking the ATV
When stopping the engine, turn off the main
switch (key) off at once
