Linhai M565Li - SPECIFICATIONS

M565Li OWNER’S/OPERATOR’S MANUAL
19. SPECIFICATION
99
Model
M565L （T3b） M565L （EURO Ⅳ）
Fuel capacity 14.5L 14.5L
Engine Oil Capacity 2.2L 2.2L
Ground Clearance 249mm 249mm
Height 1378mm 1265mm
Length 2365mm 2330mm
Width 1199mm 1199mm
Seat Height 900mm 900mm
Wheelbase 1455mm 1455mm
Turning diameter 7000mm 7000mm
Dry Weight 385kg 384kg
Front Rack 10kg 10kg
Rear Rack 20kg 20kg
Load Capacity
(Combined Rider& Payload)
170kg 170kg
Tongue Weight 10kg 10kg
Tow Capacity 203kg 190kg
Drive System
Drive System CVT - L/H/N/R/P
Tire Pressure front 48kPa
rear 48kPa
Brake System
Service Brake Front Brake
Hydraulic Disc
Rear Brake
Parking Brake All Wheel Hydraulic Lock
Auxiliary Brake Rear Brake Hydraulic Disc
Tires
Front Rear
AT25 x 8.00-12 40L AT25 x 10.00-12 50L
