Link HD System Manual
Document # -HD System Man Iss 1.1 Issue 1.1 06/11/2007
Page 17 of 31
2.4.2.5 RS232 Menu
Sub menu Options Comments
Off Inhibits any RS232 data being output.
Data ###
On Allows RS232 data to be output. See remote control protocol for details of data
types and encoding settings.
Baud rate #### None Automatically detects the baud rate of the data stream. If no data is detected,
(null) is displayed.
Parity None Automatically detects the baud rate of the data stream.
2.4.2.6 Unit Menu
Sub menu Options Comments
Address # None Allows the unit address to be set where multiple receivers are controlled from
the same source. A value between 0001 and 9999 can be set.
LNB Power ###
Yes Power is supplied via the down leads to the down converter. On the display
LNB ON is shown in the bottom left corner.
No There is no low voltage power supplied to the down leads.
OSD Status Not supported in this version of code.
Soft version: ### None Displays the version of the currently installed firmware.
FPGA version: ## None Displays the version of the currently installed FPGA code.
SerNum ###### None Displays the electronic serial number of the unit.
Lcod ‘//////////
None Allows a unique hexadecimal string (licence code) to be entered so that the
unit’s features can be upgraded or downgraded. The hex string is issued by
Link providing the correct conditions (payment) are satisfied.
Aux Address # Not supported in this version of code.
Lock ### Off Allows full control of all settings on the receiver.
On Allows the User to scroll through the menus but will not allow any changes to be
made to settings – other than Lock Off ! A padlock symbol is shown on the
display when Lock is on.
LCD Contrast # None Allows the contrast of the display to be varied in 16 steps.
Mode #### 10MHzCOFDM 10MHz (Single) LMS-T modulation
20MHzCOFDM 2 x 10MHz (Dual) LMS-T modulation
ASI ASI stream input (decode only) operation
DVBT/LMST DVB-T 10MHz Channel modulation
ASI Lock None Displays whether the decoder is locked to an incoming ASI stream
L3010 Use this setting for an older Link manufactured down converter. This setting
automatically enters the correct local oscillator frequency in the Demod menus
L3030 New style Link down converter with 1.95GHz to 2.7GHz filter
L3031 New style Link down converter with 2.00GHz to 2.11GHz filter
L3032 New style Link down converter with 2.1GHz to 2.2GHz filter
L3033 New style Link down converter with 2.2GHz to 2.3GHz filter
L3034 New style Link down converter with 2.3GHz to 2.4GHz filter
L3035 New style Link down converter with 2.4GHz to 2.5GHz filter
L3037 New style Link down converter with 2.5GHz to 2.7GHz filter
L3060 Link down converter with 3.4GHz to 3.58GHz filter
Other
Use this setting for other manufacturers down converters. The local oscillator
setting must be manually entered in the Demod menus.
By entering a value of 0 for the down converter local oscillator, the receiver can
be tuned in the range of 860MHz to 470MHz.
Dconv Type #####
None With this setting, the receiver automatically tunes to 70MHz.
Unit PCB ###### None Not supported in this version of code.
2.4.2.7 CCU Menu - Camera Control
Only available if connected to the L1255 data transmitter.
Sub menu Options Comments
Camera Type Select camera
type
Philips, Sony ….
Frequency Enter required
frequency
Set UHF transmitter frequency 450-470MHz
