Link HD System Manual
Document # -HD System Man Iss 1.1 Issue 1.1 06/11/2007
Page 3 of 31
1 General
Please refer to the Link Research website, www.linkres.co.uk
, for the latest information. A customer section is available
within the Support Area.
This manual is intended to support the two frequency variants of the Link HD transmitter and down converters.
As the operation of these two variants is identical, all references in the text will be to the 2GHz variant; L1403 and L3020.
Frequency Band Transmitter Down Converters / Filter
1.95GHz to 2.7GHz L1403 L3020 + L3030
3.4GHz to 3.58GHz L1405 L3050 + L3060
In all support requirements or in case of unit failure please contact Link directly. Always refer to the Link web site for
firmware upgrades, interoperability and support in general before contacting Link Research Ltd.
Link Research Ltd.
http://www.linkres.co.uk/support.php
Email:- mailto:support@linkres.co.uk
Tel:- +44 (0)1923 474060
1.1 Safety
The L2132 Receiver unit and L1255 Data Transmitter must be earthed; either via an earthed mains supply or a separate
earth connection.
Operate within the environmental limits of the product and ensure there is adequate ventilation.
Only authorised trained personnel should open the product. There are no functions that require the user to gain access to
the interior of the product and the warranty will be invalidated if the unit seals are broken.
For safety guidelines relating to the use of microwave radiation please refer to the document available at the Link Research
website. http://www.linkres.co.uk/support.php
1.2 Compliance
This equipment has been designed to meet the requirements of the following:-
EN60950 European Safety of information technology equipment including business equipment.
UL 1950USA Safety of information technology equipment including business equipment.
EN 55022 European Emission Standard equipment-class A.
EN 55103-2 European Generic Immunity Standard.
ETSI EN301 - 489 - 3 For Radio Equipment in the range of 1GHz to 40GHz
ETSI EN300 - 440 -1 For Radio Equipment in the range of 1GHz to 40GHz
The CE mark is affixed to the LinkHD and the EC Declaration of Conformity and Technical File is available on request.
For further information please refer to the Link Research Ltd website. www.linkres.co.uk
,
