3.5.1.5 OCP Interface – Sony
Connector - Hirose 8way
‘Lemo’ Type Function
Pin 1
Pin 2
Pin 3
Pin 4
Pin 5
Pin 6
3.5.1.6 Antenna
50 BNC connector for connection to the UHF antenna.
3.5.2 Mechanical
Height 44mm, Width 210mm, Depth 320mm - including rear panel connectors
Small form 1U, ½ width 19” rack mount
~1.7kg weight
Ambient 0ºC to +40ºC
3.5.3 Power
AC input option 100VAC to 240VAC 50Hz to 60Hz
DC input option 10VDC to 32VDC (-ve chassis earth)
