Link HD System Manual
Document # -HD System Man Iss 1.1 Issue 1.1 06/11/2007
Page 9 of 31
Remux Source SDI/ASI,Off,Aux
Rate Displays Current Rate
Active Displays state
Encoder Encoder On,Off,On If Video
Profile 4:2:0 , 4:2:2
Auto Rate On, Off
Bit Rate Sets encoder rate
Mode Standard, Low Delay
Aspect Ratio 4:3, 16:9
GOP Length 1:15
VBI in Pict On, Off
PID 0 - 9999
Audio A Audio A Off, MPEG II Layer 1, MPEG II Layer 2,
Linear PCM
* video input
required
Input Test Tone*, ID, AES-EBU, SDI
embedded,Analogue
Bit Rate 128, 160, 192, 224, 256, 320, 384KBps
Mode Dual Mono, Stereo
Language Eng, Fre,Ger,Spa
PID 0-9999
Audio A Lock Status
Tone Level Set test tone output level
Line/Mic Select analogue input
Phantom Power On, Off
Right Mic Level Set Mic left level
Left Mic Level Set Mic right level
Right Line Level Set Line left level
Left Line Level Set Line right level
Audio B As Audio A
Multiplexer ASI OP Off,188, 204 byte
Bit Rate Sets required ASI output rate
Service
Network
PMT PID Sets PID 0 - 9999
PCR PID Sets PID 0 - 9999
Local Service On, Off
Program ID Sets ID 0 - 9999
RS232 Data Data Off, TTV, CJM2, Fast
Baud Rate 1200-38400
PID Sets PID 0 - 9999
2.1.3 Transmitter Setup
It is important that when changing between modes of operation it is necessary to check and re-select certain operating
parameters due to interaction of some of these parameters.
For example when changing from DVB-T to LMS-T mode it will be necessary to reset the required modulation scheme.
In the following examples the menus are described by :-- Tab Menu / Sub Menu / Function
Following a ‘Restore Factory Defaults’ (Setup/Profiles/Restore Defaults) it will be necessary to select the required operating
mode and modulation configuration as the factory defaults will not currently give an operational setup and may result in
‘garbage’ characters on the display.
