3.1.2.5 DC Power and Power Switch
L1403 ~19.5W 12V DC nominal @ 1.6A (9V minimum, 18V maximum)
L1420 ~4W 12V DC nominal @ 0.3A (9V minimum, 18V maximum)
Performance is degraded below 11.0V.
Chassis Socket Connector :- LEMO ECG1B304CLV
Mating Cable Plug :- LEMO FGG1B304CLAD62Z
Link Cable Assembly– flying leads :- L0003
LEMO Pin Function
1 GND
2 GND
3 +12V supply
4 +12V supply
Power Switch
The power switch is used to control the L1403/L1420 when power is supplied from the rear ‘clip on’ battery plate.
The camera interface plate is NOT switched when fed from the rear battery plate and therefore the camera switch must be
used to control the camera.
When using this external DC power input the L1403/L1420 is NOT switched using the On/Off Power switch. An external
switch on the power supply or battery belt must be used to control the L1403/L1420.
When using this external LEMO connector the switch WILL control the power fed forward to the camera via the camera
interface plate.
3.1.2.6 RF
100mW into 50 – switchable. 10, 50 or 100mW.
50 chassis mounted ‘N’ type bulkhead socket.
3.1.2.7 RS232 Data & Control Port
The six pin connector provides the RS232 input / output of both the User Data and also Remote Control of the transmitter
unit.
Chassis Socket Connector :- LEMO EEF0B306CLV
Mating Cable Plug :- LEMO FGG0B306CLAD52Z
LEMO Pin Function
Pin 1 Tx Data (output)
Pin 2 Rx Data (input)
Pin 3 0v
Pin 4 Tx Control (output)
Pin 5 Rx Control (input)
Pin 6 0v
3.1.2.8 USB Data Port
A USB2 ‘Mini B’ style connector is to allow for serial communication with the unit.
Chassis Socket Connector :- Molex 67503-0020
USB Pin Function
Pin 1 Vbus
Pin 2 D-
Pin 3 D+
Pin 4
Pin 5 0V
