Link HD System Manual
Document # -HD System Man Iss 1.1 Issue 1.1 06/11/2007
Page 24 of 31
3.2.1.1 Camera Control Data
Serial data interface to the camera head using appropriate lead. The function of the pins is automatically configured
depending on the selected camera type.
Chassis Socket Connector :- LEMO EEG0B305CLV
Mating Cable Plug :- LEMO FGG0B305CLAD52Z
Lead Part Number Camera Type
L0016 Philips LDK Series
L0017 Sony BVP Series
L0024 Ikegami
3.2.1.2 Tally
Not used on current design.
Chassis Socket Connector :- LEMO EEF0B306CLL
Mating Cable Plug :- LEMO FGG0B306CLAD52Z
