1
Présentation du produit
Linksys EA-Series
1
Présentation du produit
EA6900
Vue de dessus
Voyant
Voyant d’état d’alimentation : Reste constamment allumé lorsque
connecté au secteur et lorsqu’une connexion Wi-Fi Protected Setup
est correctement établie. Clignote lentement pendant le démarrage,
lors des mises à jour du microprogramme, et lors d’une connexion Wi-
Fi Protected Setup. Clignote rapidement lors d’une erreur pendant la
procédure Wi-Fi Protected Setup.
Vue arrière
Ports Ethernet
Bouton Wi-Fi
Protected Setup
Port Internet
Port d’alimentation
Bouton Réinitialisation
Port(s) USB
Ports pour antennes ajustables— Les trois antennes externes réglables
incluses doivent être connectés au routeur que ce dernier soit mis en
marche. Vissez le connecteur de l’antenne dans le sens horaire dans le
port sur le routeur.
REMARQUE
Pour des performances optimales, positionnez les antennes
latérales à un angle de 30°, tel que démontré sur l’image de gauche.
Bouton Wi-Fi Protected Setup™ — Appuyez sur pour configurer
facilement la sécurité sans fil sur les périphériques réseau compatibles
Wi-Fi Protected Setup.
Ports USB: Connectez et partagez un disque USB ou une imprimante
USB.
Ports Ethernet: Branchez les câbles Ethernet aux ports gigabit bleus
(10/100/1000) et aux périphériques réseau Ethernet filaires.
Port Internet: Connectez un câble Ethernet à ce port jaune et à votre
modem.
Bouton de réinitialisation: Appuyez sur ce bouton pendant 10 secondes
(jusqu’à ce que les voyants des ports clignotent en même temps) pour
restaurer les paramètres d’usine du routeur. Vous pouvez également
restaurer les paramètres par défaut à l’aide de Linksys Smart Wi-Fi.
Port d’alimentation: Branchez l’adaptateur secteur fourni sur ce port
Ports pour antennes ajustables

Table of Contents

Other manuals for Linksys EA6900

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Linksys EA6900 and is the answer not in the manual?

Linksys EA6900 Specifications

General IconGeneral
Ethernet LANYes
Cabling technology10/100/1000Base-T(X)
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet LAN interface typeGigabit Ethernet
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Wi-Fi standardsWi-Fi 5 (802.11ac), Wi-Fi 4 (802.11n)
Top Wi-Fi standardWi-Fi 5 (802.11ac)
USB version3.2 Gen 1 (3.1 Gen 1)
Input current3.5 A
Rack mountingNo
Frequency band2.4 & 5 GHz
Bandwidth (first)2.4 GHz
Bandwidth (second)5 GHz
USB connector typeUSB Type-A
USB ports quantity2
Ethernet LAN (RJ-45) ports4
Supported network protocolsIPv6, FTP, IPSec, PPTP, L2TP
Antennas quantity3
Security algorithms802.1x RADIUS, WEP, WPA, WPA2, WPS
MAC address filtering-
CertificationFCC, IC, CE, DLNA
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 90 %
Operating relative humidity (H-H)10 - 80 %
LED indicatorsPower
Cables includedLAN (RJ-45)
Bundled softwareLinksys Smart Wi-Fi
Mac operating systems supportedMac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Windows operating systems supportedWindows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Output voltage12 V
Weight and Dimensions IconWeight and Dimensions
Depth184 mm
Width256 mm
Height40 mm
Weight534 g
