Page #88 background imageLoading...
Page #88 background image
3
Setting Up Your EA-Series Router
Linksys EA-Series
3
Where to find more help
Linksys.com/support (documentation, downloads, FAQs, technical
support, live chat, forums)
Linksys Smart Wi-Fi help (connect to Linksys Smart Wi-Fi, then click
Help at the top of the screen)
How to install your router
To install your router:
1.
If replacing an existing router, disconnect it. Power on your new router.
2.
Connect the Internet cable from your modem to the yellow Internet port
on your router. Wait until the power light on the front of the router is
solid.
3.
Connect to the secure wireless name shown in the Quick Start Guide that
came with your router. (You can change the network name and password
later during router setup.) If you need help connecting to the network,
refer to your device documentation CD. Note: You will not have Internet
access until router setup is complete.
4.
Open a web browser and follow the instructions to complete your
router’s setup. If instructions do not appear in the web browser, enter
linksyssmartwifi.com in the browser’s address bar.
5.
At the end of setup, follow the on-screen instructions to set up your
Linksys Smart Wi-Fi account. Use Linksys Smart Wi-Fi to easily manage
your router’s settings, such as:
Change your router’s name and password
Set up guest access
Configure parental controls
Connect devices to your network
Test your Internet connection speed
NOTE:
As part of Linksys Smart Wi-Fi account setup, you will be sent
a verification e-mail. Make sure that you open the e-mail from
Linksys and click the provided link.
Setting Up Your EA-Series Router

Table of Contents

Other manuals for Linksys EA6900

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Linksys EA6900 and is the answer not in the manual?

Linksys EA6900 Specifications

General IconGeneral
Ethernet LANYes
Cabling technology10/100/1000Base-T(X)
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet LAN interface typeGigabit Ethernet
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Wi-Fi standardsWi-Fi 5 (802.11ac), Wi-Fi 4 (802.11n)
Top Wi-Fi standardWi-Fi 5 (802.11ac)
USB version3.2 Gen 1 (3.1 Gen 1)
Input current3.5 A
Rack mountingNo
Frequency band2.4 & 5 GHz
Bandwidth (first)2.4 GHz
Bandwidth (second)5 GHz
USB connector typeUSB Type-A
USB ports quantity2
Ethernet LAN (RJ-45) ports4
Supported network protocolsIPv6, FTP, IPSec, PPTP, L2TP
Antennas quantity3
Security algorithms802.1x RADIUS, WEP, WPA, WPA2, WPS
MAC address filtering-
CertificationFCC, IC, CE, DLNA
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 90 %
Operating relative humidity (H-H)10 - 80 %
LED indicatorsPower
Cables includedLAN (RJ-45)
Bundled softwareLinksys Smart Wi-Fi
Mac operating systems supportedMac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Windows operating systems supportedWindows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Output voltage12 V
Weight and Dimensions IconWeight and Dimensions
Depth184 mm
Width256 mm
Height40 mm
Weight534 g
