Linksys LAPAC1750 User Manual

Profile
Select a profile to configure.
New Logo Upload
Logos display in the web page. Select an image file
from your local PC and click Upload.
Formats .gif, .png and .jpg are supported. File size
cannot exceed 5KB.
One profile can support one default and one new logo
image. If a second new logo is uploaded, it will replace
the first new logo.
Logo Selection
Select a logo image from the list.
Background Color
The HTML code for the background color in 6-digit
hexadecimal format. The default is #0073BA.
Font Color
The HTML code for the font color in 6-digit
hexadecimal format. The default is #FFFFFF.
Welcome Title
Customize text to go with your logo. The default is
Welcome to the Wireless Network.
Login Instruction
Customize text to go with the login box. Default text
for different authentication options:
Local Authentication/Radius Authentication
You can log in using your username and password.”
Password Only Authentication
You can log in using your password.
Local Authentication
Click Connect to log in.
User Label
Customize the username text box. Enter up to 16
characters. The default is "Username".
Password Label
Customize the user password text box. Enter up to
16 characters. The default is "Password".
Button Name
Customize the text that appears in the log in button.
Enter up to 12 characters. The default is "Connect".
Button Color
The HTML code for the background color of the
button in 6-digit hexadecimal format. The default is
#70A0D4.
Terms of Use Label
Customize the text to go with the checkbox. Enter up
to 128 characters. The default is "Check here to
indicate that you have read and accepted the
following Terms of Use."
69

Linksys LAPAC1750 Specifications

General

Modulation	-
Frequency band	2.412 - 2.462, 5.18 - 5.24, 5.745 - 5.825 GHz
Channels quantity	11 channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3at, IEEE 802.3u
Wi-Fi data rate (max)	500 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1000 Mbit/s
Quality of Service (QoS) support	Yes
Internal	No
Placement	Ceiling, Wall
Certification	FCC, CE, IC
Product color	White
Cable lock slot type	Kensington
Supported network protocols	IPv6
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Security algorithms	802.1x RADIUS, WDS, WEP, WPA, WPA2
Number of SSID supported	16
Antenna features	Integrated antenna
Input current	1.5 A
AC input voltage	12 V
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	243.08 mm
Width	236.98 mm
Height	43.69 mm
